GameCube Setup Guide

NINTENDO GAMECUBE – Setup Guide

WARNING! Contains Coin Battery/Cell Battery. Hazardous if swallowed or placed inside any part of the body. Please see instructions.

1. Unboxing & Included Components

• Nintendo GameCube console
• Nintendo GameCube controller
• AC adapter
• AV cable

2. Initial Setup Steps

Connect the Console to the TV

You can connect the Nintendo GameCube to a television using:

• Stereo AV cable (yellow = video, white/red = audio) — plug matching colours into the TV
• For TVs without AV inputs, an RF switch and RF modulator may be required (sold separately)

Connect the other end of the AV cable to the ANALOG AV OUT port on the back of the console.

Connect the Power Adapter

Insert the DC plug from the AC adapter into the DC 12V IN connector on the back of the Nintendo GameCube.
Connect the AC plug to a standard Australian power outlet or a suitable extension lead.
Use only the supplied AC adapter that is compatible with Australian mains power.

Attach the Controller

Insert the controller plug into controller socket 1 on the front of the console. Up to four controllers can be connected.

Insert a Memory Card (Optional)

Insert a compatible Nintendo GameCube Memory Card into Slot A or Slot B. Many games use a Memory Card to save progress.

3. Operating Instructions

Insert a Game Disc

1. Press the OPEN button to raise the disc cover.
2. Place a Nintendo GameCube Game Disc onto the spindle, label side up.
3. Press the disc gently into place until it is seated correctly.
4. Close the disc cover firmly.

Power On the Console

Press the POWER button. The power indicator light will illuminate.

Select the TV Input

Switch your TV to the AV input or channel where the Nintendo GameCube is connected.

Start Playing

The Nintendo GameCube startup screen will appear. If a game disc is inserted, select the game from the menu or allow it to start automatically, depending on the title.

4. Using the Controller

The Nintendo GameCube controller features:

• Control Stick and +Control Pad
• A, B, X and Y buttons
• L, R and Z buttons
• START/PAUSE button

Refer to each game’s manual for specific controls and controller accessory support.

Basic Troubleshooting

• If there is no picture, confirm the TV is set to the correct AV input or channel
• Check that the Stereo AV cable is fully connected to both the TV and the console
• Check that the AC adapter is fully connected and the power indicator light is on
• Make sure the disc cover is fully closed before starting a game
• If a disc will not read, check for dirt or scratches and clean it gently from the centre outward with a soft cloth
• If the problem continues, try another compatible GameCube disc

5. Saving Game Data

Most games save progress to a Nintendo GameCube Memory Card (sold separately).
Insert the Memory Card before starting the game and follow the on-screen save instructions.
Do not remove or insert a Memory Card while saving, copying, moving, erasing, or formatting data this may damage the Memory Card or console data/system.

6. Maintenance & Care

Cleaning the Console

Use a soft, dry cloth to clean the exterior surfaces.
Do not use liquid cleaners, solvents, or abrasive materials.
Keep the vents clear and do not block airflow around the console.

Game Disc Care

• Hold discs by the edges only
• Keep discs clean and free from fingerprints, dust, and scratches
• If needed, wipe with a soft cotton cloth from the centre outward
• Do not use paper towels, strong cleaners, or excessive moisture
• Store discs away from heat, sunlight, and humidity

⚠️ NINTENDO GAMECUBE – Warnings & Safety Precautions

IMPORTANT SAFETY INFORMATION

Carefully read these warnings before using the Nintendo GameCube console.
SAVE THESE INSTRUCTIONS.
If used by children, these instructions should be read and explained to them by an adult.

WARNING - BUTTON BATTERY

WARNING: This console contains a lithium button / coin cell battery.

Do not handle damaged or leaking lithium-ion batteries. If the internal battery fluid leaks, stop using the product immediately and contact technical support for assistance. If the fluid gets on to your clothes, skin or into your eyes, immediately rinse the affected area with clean water and consult your doctor. The battery fluid can cause blindness.

Do not allow the battery to come into contact with fire or subject it to extreme temperatures such as in direct sunlight, in a vehicle exposed to the sun or near a heat source. Never attempt to open, crush, heat, or set fire to the battery.

WARNING – SEIZURES

Some people may have seizures or blackouts triggered by light flashes or patterns while watching TV or playing video games, even if they have never had a seizure before.
Consult a doctor before use if you or your child have ever experienced:

• Seizures
• Loss of awareness
• Symptoms linked to an epileptic condition

Stop playing immediately and consult a doctor if you or your child experience:

• Convulsions
• Eye or muscle twitching
• Loss of awareness
• Altered vision
• Involuntary movements
• Disorientation

Reduce seizure risk:

• Sit or stand as far from the screen as possible
• Play on the smallest available television screen
• Do not play if you are tired or need sleep
• Play in a well-lit room
• Take a 10–15 minute break every hour

WARNING – REPETITIVE MOTION INJURIES & EYESTRAIN

Playing video games can make your muscles, joints, skin, or eyes hurt after a few hours.
Follow these guidelines to help avoid tendinitis, carpal tunnel syndrome, skin irritation, or eyestrain:

• Avoid excessive play
• Take a 10–15 minute break every hour, even if you do not think you need it
• If your hands, wrists, arms, or eyes become tired or sore, stop and rest for several hours before playing again
• If soreness continues during or after play, stop playing and see a doctor

WARNING – ELECTRIC SHOCK

To avoid electric shock when using this system:

• Do not use the Nintendo GameCube during a lightning storm
• Use only the AC adapter that comes with the system
• Do not use the AC adapter if cords or wires are damaged, split, or broken
• Make sure the AC adapter cord is fully inserted into the wall outlet or extension cord
• Always disconnect plugs by pulling on the plug, not the cord
• Make sure the power switch is OFF before removing the AC adapter cord from an outlet

Do not place the console where it may come into contact with liquids, excessive humidity, dust, soot, lint, or smoke.

Keep ventilation openings clear, and do not place the system on carpet or other surfaces that may block airflow.

WARNING – MOTION SICKNESS

Stop playing if you feel dizzy or nauseous.

Do not drive or engage in other demanding activity until you feel better.

CAUTION – LASER DEVICE / DO NOT DISASSEMBLE

The Nintendo GameCube is a Class I laser product.
Do not attempt to disassemble the console. Refer servicing to qualified personnel only.
Use of controls, adjustments, or procedures other than those specified may result in hazardous radiation exposure.

CAUTION – TV SCREEN DAMAGE

Some televisions can be damaged by displaying stationary images for extended periods. Follow your TV manufacturer’s instructions and avoid leaving the GameCube image paused on screen for long periods.

CAUTION – GAME DISC USE & HANDLING

Use only PAL-region Nintendo GameCube Game Discs compatible with Australian systems. The system does not play CDs or DVDs.

• Do not touch the lens inside the console
• Do not force a disc into position
• Remove the Game Disc after use
• Do not store the console or discs in humid places or on the floor

IMPORTANT USE NOTE

Parents should monitor children during gameplay and ensure the system is used only as intended in a safe indoor environment.

This Preowned product is refurbished by EB Games which is not endorsed or guaranteed by its original manufacturer,
